DX Long Pulse Series
Nanosecond Lasers

Long Pulse Nanosecond Laser

DX-355-LP | DX-355-HLP

DX-532-LP | DX-532-HLP

Download Brochure Here

Features

  • Long pulse at high powers:
    Up to 30 W UV, ~12 to ~300 ns,
    Up to 50 W Green, ~65 to ~340 ns
  • Longer pulses at high repetition rates:
    ~250 ns at 200 kHz for HLP model,
    ~340 ns at 200 kHz for LP model
  • Reliable, low COO, non-consumable design
    Patented intracavity harmonic UV & Green generation, no damaging indexing of the harmonic crystals
  • Unique long pulse DPSS nanosecond laser
    Unique in the market for long pulse needs
  • Excellent TEM00 beam quality:
    Typical M2 < 1.2
  • Superior pulse stability:
    Typical < 1.5 %
  • Total Pulse Control for ultimate integrability into systems:
    Duty Control to change output power while allowing for longer pulse widths than the standard operating values
    PEC (Power or Pulse Energy Control)

Overview

Our DX Series Long Pulse Nanosecond Lasers have smaller form factor, higher performance, and more flexibility in pulse width compared to its ancestor, the DSH series, providing the most compact UV output powers from 15W to 30W and Green output powers from 30W to 50W in a longer pulse configuration.  Shorter pulse versions are available.**

** For shorter pulse width models, please see the DX Series Short Pulse Nanosecond Lasers
