RGLX Series
Picosecond Lasers

High Pulse Energy

Picosecond Lasers

High pulse energy: Up to 4 mJ at 1 kHz IR, & Up to 2.5 mJ at 1 kHz Green. With 25-50 ps pulse widths.

IR: RGLX-1064-2 | RGLX-1064-4

GRN: RGLX-532-1.5 | RGLX-532-2.5

RGLX Series High Pulse Energy Picosecond Lasers Brochure


  • Variable repetition rate: single shot to 5kHz
  • Excellent beam quality (M2<1.3)
  • Small form factor, compact
  • Industrial grade
  • Diode pumped technology
  • Wide range of powers and harmonic options available
  • All-in-one single box design


Photonics Industries’ RGLX Series picosecond lasers offer low pulse widths (< 25 ps), high pulse energies (up to 4 mJ), and high repetition rates (up to 5 kHz). With no separate utility module, the all-in-one (AIO) RGLX Series is a pioneering laser for research, especially fulfilling new and emerging requirements in laser ranging (SLR), and also offers industrial sectors the pulse energy, repetition rate, and convenient AIO package for integration into systems for efficient micro-processing and meso-processing.
